Product Details:
Payment & Shipping Terms:
|
| Product Name: | Gallium Oxide, Gallium(III) Oxide | Molecular Formula: | Ga2O3 |
|---|---|---|---|
| Color: | White | Form: | Powder |
| CAS: | 12024-21-4 | Melting Point: | 1740 °C |
| Density: | 6.44 G/mL | Solubility: | Soluble In Acids. Insoluble In Water |
| Storage Conditions: | Stable. Incompatible With Magnesium. | Application Area: | Phosphor For White LED, Gadolinium Gallium Garnet Crystal And Ga-based Semiconductor Materials |
| High Light: | tellurium dioxide,bismuth trioxide |
||
High Purity Gallium Oxide Ga2O3 CAS 12024-21-4 For Fluorescent Material
Name: Gallium oxide, Gallium(III) oxide Molecular formula: Ga2O3
CAS: 12024-21-4 Molecular weight: 187.44
Description: Gallium oxide, is the most stable oxide of gallium. White triangular crystalline particles. Insoluble in water. Slightly soluble in hot acid or alkali solution. There are five isomers of Ga2O3: α, β, γ, δ, ε. The most stable one is β-isomer. When heated to over 1000℃ or heated to over 300℃ in hydrothermal condition (i.e. wet process), all other isomers are converted to β-isomer. All kinds of pure isomers can be prepared by different methods. Gallium oxide can be dissolved in dilute nitric acid, hydrochloric acid and sulfuric acid. The burnt Ga2O3 is insoluble in these acids, even in concentrated nitric acid, and also in the aqueous solution of strong alkali. It can only be dissolved by melting NaOH, KOH or KHSO4 together with K2S2O7. Gallium chloride is formed by melting with twice of NH4Cl at 250℃.
Specification:
| Name | Ga2O3_6N | Ga2O3_5N | Ga2O3_4N | ||
| Molecular formula | Ga2O3 | Ga2O3 | Ga2O3 | ||
| CAS | 12024-21-4 | 12024-21-4 | 12024-21-4 | ||
| Ga2O3 content | % | ≥99.9999 | ≥99.999 | ≥99.99 | |
| Impurity content | Na | % | ≤0.1×10-4 | ≤1.5×10-4 | ≤5.0×10-4 |
| Ca | % | ≤0.2×10-4 | ≤1.0×10-4 | ≤5.0×10-4 | |
| Cr | % | ≤0.05×10-4 | ≤1.0×10-4 | ≤3.0×10-4 | |
| Fe | % | ≤0.1×10-4 | ≤1.5×10-4 | ≤10×10-4 | |
| Ni | % | ≤0.04×10-4 | ≤1.5×10-4 | ≤10×10-4 | |
| property | White crystal powder | ||||
| Application | Phosphor for white LED, gadolinium gallium garnet crystal and Ga-based semiconductor materials, catalyst | ||||
| package | Sealed packaging, flexible packaging according to customer needs | ||||
Packing: 1 kg or 5 kg per package, 25 kg carton, also provide small package: 100g, 500g, and other small packages
Uses: Gallium oxide is a kind of transparent oxide semiconductor material, which has a wide application prospect in optoelectronic devices. It is used as the insulating layer of Ga-based semiconductor material and ultraviolet filter. It can also be used as an O2 chemical detector. Gallium oxide nanorods have potential applications in integrated circuits.
